不同来源的霍乱弧菌毒力特征的质谱学分析

屠博文; 薛银刚; 姚萍; 王楠; 黎俊宏; 唐宏兵; 杜强

doi:10.13386/j.issn1002-0306.2020060092

不同来源的霍乱弧菌毒力特征的质谱学分析

1. 常州市疾病预防控制中心, 江苏常州 213022;
2. 常州大学环境与安全工程学院, 江苏常州 213003;
3. 泰州医药高新区市场监督管理局医疗器械处, 江苏泰州 225300

基金项目:

江苏省卫生健康委科研课题面上项目（H2018098）；常州市重大科技支撑计划（社会发展）（CE20185048和CE 20175022）；江苏省预防医学会课题（Y2018023）；常州市应用基础研究计划（CJ20190071）。

详细信息

作者简介:
屠博文(1984-),男,博士,副研究员,研究方向:微生物质谱鉴定研究,E-mail:tbwchangzhou@163.com。

通讯作者:
杜强(1976-),男,本科,副检验技师,研究方向:微生物检测,E-mail:tbwchangzhoutbw@sina.com。

中图分类号: TS201.3
计量
- 文章访问数: 0176
- HTML全文浏览量: 08
- PDF下载量: 019
出版历程
- 收稿日期: 2020-06-08
- 网络出版日期: 2021-03-15
- 刊出日期: 2021-03-14

Virulence Characteristics Application of Vibrio cholera from Different Source by Microbial Mass Spectrometry

1. Changzhou Center of Disease Prevention and Control, Changzhou 213022, China;
2. School of Environmental and Safety Engineering, Changzhou University, Changzhou 213003, China;
3. Medical device department of market supervision administration of Taizhou pharmaceutical high-tech zone, Taizhou 225300, China

摘要

摘要: 目的：分析本地区食品风险监测样品中霍乱弧菌的分布，评价使用VITEK-MS微生物质谱进行霍乱弧菌快速鉴定的优劣。方法：从淡水产品和病人分离获得霍乱弧菌，分别进行VITEK-2生化鉴定和VITEK-MS质谱鉴定。血清凝集和胶体金显色法检测霍乱弧菌血清型，PCR检测ctx毒力基因。通过全基因组测序分析霍乱弧菌毒力基因类型。结果：经快速鉴定检出23株霍乱弧菌，17株为非O1/O139血清型，6株为O139型并且携带ctx毒力基因。VTIEK-MS微生物质谱检出的霍乱弧菌具有典型的指纹图谱特征，O139型霍乱弧菌具有典型的特有峰和缺失峰特征。全基因组测序显示O139血清型具ctxAB、ace和tcp毒力岛等毒力基因，而非O1/O139株则只具有辅助毒力因子，个别腹泻病例株携带了zot基因。结论：非O1/O139和O139型霍乱弧菌无论在毒力基因种类和质谱特征上都具有显著的差异，广泛应用VITEK-MS微生物快速鉴定技术进行霍乱弧菌血清鉴定有望成为霍乱监测的新助力。
- 霍乱弧菌 /
- 微生物质谱(VITEK-MS) /
- 全基因组测序 /
- 毒力基因 /
- 指纹图谱
Abstract: Objective: To analysis the regularities of distribution of Vibrio cholera from food risk monitoring samples and evaluate the merits of VITEK-MS rapid analysis methods in identification of Vibrio cholera. Methods: V. cholera strains were isolated from freshwater products and patients. The VITEK-MS and VITEK-2 identification were operated respectively. The serotype was detected by serum agglutination and immunogold. The virulence genes ctxAB was detected by qPCR. All the virulence genes in different types of strains were analyzed by whole genome sequencing. Results: 17 of the 23 V. cholera strains were non-O1/O139 serotype. 6 strains were detected as O139 V. cholera and ctxAB gene carrier. All the V. cholera strain showed typical mass spectral characteristics based on the fingerprint spectrum. The particular and lacking peaks patterns of O139 V. cholera were representative for Serotype identification. ctxAB, ace and tcp islands genes were harbored in O139 Vibrio cholera, but only auxiliary virulence factor can be detected in non-O1/O139 Vibrio cholera except zot gene. Conclusion: There are many differences between the O139 and non-O1/O139 Vibrio cholera strains in whether virulence gene type or fingerprint spectrum. The thorough application for serotype identification by using microbial mass spectrometry may be a new assistance for cholera surveillance.
- Vibrio cholera /
- microbial mass spectrometry(VITEK-MS) /
- whole genome sequencing /
- virulence genes /
- fingerprint spectrum

HTML全文

参考文献(33)

[1]	Ali M,Nelson A R,Lopez A L,et al. Updated Global burden of cholera in endemic countries[J]. PLoS Neglected Tropical Diseases,2015,9(6):e0003832. DOI:10.1371/journal. pntd. 0003832.
[2]	Ramamurthy T,Das B,Chakraborty S,et al. Diagnostic techniques for rapid detection of Vibrio cholerae O1/O139[J]. Vaccine. 2020,38:A73-A82.
[3]	Faruque S M,Chowdhury N,Kamruzzaman M,et al. Genetic diversity and virulence potential of environmental Vibrio cholera population in a cholera-endemic area[J]. Proc Natl Acad Sci U S A,2004,101(7):2123-8.
[4]	Gong L,Yu P,Zheng H J,et al. Comparative genomics for non-O1/O139Vibrio cholerae isolates recovered from the Yangtze River Estuary versus V. cholerae representative isolates from serogroup O1[J]. Molecular Genetics and Genomics,2019,294(2):417-430.
[5]	Fu S Z,Hao J W,Jin S B,et al. A Human intestinal infection caused by a novel non-O1/O139 Vibrio cholerae genotype and its dissemination along the river[J]. Frontiers in Public Health,2019,7:100.
[6]	Baker-Austin C,Trinanes J A,Taylor N G H,et al. Emerging Vibrio risk at high latitudes in response to ocean warming[J]. Nature Climate Change,2012,3(1):73-77.
[7]	Frank C,Littman M,Alpers K,et al. Vibrio vulnificus wound infections after contact with the Baltic Sea,Germany[J]. Euro Surveillance,2006,11(8):E060817.1.
[8]	Kim E J,Yu H J,Lee J H,et al. Replication of Vibrio cholerae classical CTX phage[J]. Proc Natl Acad Sci USA,2017,114(9):2343-2348.
[9]	夏晓滨. 霍乱弧菌生物被膜[J]. 中华微生物学和免疫学杂志,2008,28(4):381-384.
[10]	Huq A,Whitehouse C A,Grim C J,et al. Biofilms in water,its role and impact in human disease transmission[J]. Current Opinion in Biotechnology,2008,19(3):244-247.
[11]	Chang Y W,Kjær A,Ortega D R,et al. Architecture of the Vibrio cholerae toxin-coregulated Pilus machine revealed by electron cryotomography[J]. Nature Microbiology,2017,2:16269.
[12]	Ng D,Harn T,Altindal T,et al. The Vibrio cholerae minor pilin TcpB initiates assembly and retraction of the toxin-coregulated Pilus[J]. PLoS Pathogens,2016,12(12):e1006109.
[13]	Rahman M H,Biswas K,Hossain M A,et al. Distribution of genes for virulence and ecological fitness among diverse Vibrio cholerae population in a cholera endemic area:Tracking the evolution of pathogenic strains[J]. DNA and Cell Biology,2008,27(7):347-355.
[14]	Chow K H,Ng T K,Yuen K Y,et al. Detection of RTX toxin gene in Vibrio cholerae by PCR[J]. Journal of Clinical Microbiology,2001,39(7):2594-2597.
[15]	Satchell K J F.MARTX,multifunctional autoprocessing repeats-in-toxin toxins[J]. Infection and Immunity,2007,75(11):5079-5084.
[16]	Erler R,Wichels A,Heinemeyer E A,et al. Vibrio base:A MALDI-TOF MS database for fast identification of Vibrio spp. that are potentially pathogenic in humans[J]. Systematic and Applied Microbiology,2015,38(1):16-25.
[17]	Vidal L M R,Venas T M,Gonçalves A R P,et al. Rapid screening of marine bacterial symbionts using MALDI-TOF MS[J]. Archives of Microbiology,2020,202(8):2329-2336.
[18]	Kazazić S P,Topić Popović N,Strunjak-Perović I,et al. Matrix-assisted laser desorption/ionization time of flight mass spectrometry identification of Vibrio(Listonella)anguillarum isolated from sea bass and sea bream[J]. PLoS One,2019,14(11):e0225343.
[19]	Krishnamurthy T,Ross P L,Rajamani U. Detection of pathogenic and non-pathogenic bacteria by matrix-assisted laser desorption/ionization time-of-flight mass spectrometry[J]. Rapid Communications in Mass Spectrometry:RCM,1996,10(8):883-888.
[20]	Bauer A,Rørvik L M. A novel multiplex PCR for the identification of Vibrio parahaemolyticus,Vibrio cholerae and Vibrio vulnificus[J]. Letters in Applied Microbiology,2007,45(4):371-375.
[21]	Schirmeister F,Dieckmann R,Bechlars S,et al. Genetic and phenotypic analysis of Vibrio cholerae non-O1,non-O139 isolated from German and Austrian patients[J]. European Journal of Clinical Microbiology & Infectious Diseases,2014,33(5):767-778.
[22]	Chatterjee S,Ghosh K,Raychoudhuri A,et al. Incidence,virulence factors,and clonality among clinical strains of non-O1,non-O139Vibrio cholerae isolates from hospitalized diarrheal patients in Kolkata,India[J]. Journal of Clinical Microbiology,2009,47(4):1087-1095.
[23]	Pang B,Yan M Y,Cui Z G,et al. Genetic diversity of toxigenic and nontoxigenic Vibrio cholerae serogroups O1 and O139 revealed by array-based comparative genomic hybridization[J]. Journal of Bacteriology,2007,189(13):4837-4849.
[24]	Bhattacharya T,Chatterjee S,Maiti D,et al. Molecular analysis of the rstR and orfU genes of the CTX prophages integrated in the small chromosomes of environmental Vibrio cholerae non-O1,non-O139 strains[J]. Environmental Microbiology,2006,8(3):526-634.
[25]	Mauritzen J J,Castillo D,Tan D M,et al. Beyond cholera:Characterization of zot-encoding filamentous phages in the marine fish pathogen Vibrio anguillarum[J]. Viruses,2020,12(7):730.
[26]	Shanley J,Kanj A,El Zein S,et al. Non-O1,non-O139Vibrio cholerae bacteremia in an urban academic medical center in the United States[J]. IDCases,2019,15:e00527.
[27]	Takemura T,Murase K,Maruyama F,et al. Genetic diversity of environmental Vibrio cholerae O1 strains isolated in Northern Vietnam[J]. Infection,Genetics and Evolution,2017,54:146-151.
[28]	Xue H,Xu Y,Boucher Y,et al. High frequency of a novel filamentous phage,VCY φ,within an environmental Vibrio cholerae population[J]. Applied and Environmental Microbiology,2012,78(1):28-33.
[29]	Faruque S M,Bin Naser,Fujihara K,et al. Genomic sequence and receptor for the Vibrio cholerae phage KSF-1phi:Evolutionary divergence among filamentous vibriophages mediating lateral gene transfer[J]. Journal of Bacteriology,2005,187(12):4095-4103.
[30]	Faruque S M,Kamruzzaman M,Asadulghani,et al. CTXphi-independent production of the RS1 satellite phage by Vibrio cholera[J]. Proc Natl Acad Sci U S A,2003,100(3):1280-5.
[31]	Paauw A,Trip H,Niemcewicz M,et al. OmpU as a biomarker for rapid discrimination between toxigenic and epidemic Vibrio cholerae O1/O139 and non-epidemic Vibrio cholerae in a modified MALDI-TOF MS assay[J]. BMC Microbiol,2014,14:158.
[32]	Chaika S O,Telesmanich N R,Lomov Y M. Mass spectrometry virulence marker Vibrio cholera[J]. Klinicheskaia Laboratornaia Diagnostika,2018,63(7):445-449.
[33]	Dieckmann R,Strauch E,Alter T. Rapid identification and characterization of Vibrio species using whole-cell MALDI-TOF mass spectrometry[J]. Journal of Applied Microbiology,2010,109(1):199-211.
