Modification of Chitosan-Pectin Beads Adsorbent and Its Application for the Removal of Pb (II) from C-phycocyanin

LIU Yuhuan; GUAN Rui; CAO Leipeng; ZHOU Yue; HUANG Zhenghua; XUE Mingxiong; ZHOU Jiawen

doi:10.13386/j.issn1002-0306.2023020098

Volume 44 Issue 22

Nov. 2023

Turn off MathJax

Article Contents

Abstract

References

Science and Technology of Food Industry > 2023 > 44(22): 68-75. > DOI: 10.13386/j.issn1002-0306.2023020098

LIU Yuhuan, GUAN Rui, CAO Leipeng, et al. Modification of Chitosan-Pectin Beads Adsorbent and Its Application for the Removal of Pb (II) from C-phycocyanin[J]. Science and Technology of Food Industry, 2023, 44(22): 68−75. (in Chinese with English abstract). doi: 10.13386/j.issn1002-0306.2023020098.

Citation:

PDF (2351 KB)

Modification of Chitosan-Pectin Beads Adsorbent and Its Application for the Removal of Pb (II) from C-phycocyanin

1.
Engineering Research Center for Biomass Conversion, State Key Laboratory of Food Science and Technology, Ministry of Education, Nanchang University, Nanchang 330047, China
2.
Research Institute of Quality, Safety and Standards of Agricultural Product, Jiangxi Academy of Agricultural Sciences, Nanchang 330200, China
3.
Beihai Shengbada Biotechnology Limited Company, Beihai 536000, China

More Information

Received Date: February 12, 2023
Available Online: September 19, 2023

Graphical Abstract

Abstract

Abstract

Chitosan-pectin gel beads (CPB) have high potential for removing heavy metals from food. This study aimed to improve their stability, recyclability, and adsorption capacity by modified CPB with gelatin (Gel) and carboxymethyl cellulose sodium (CMC). The structural characteristics of the modified CPBs were characterized using Fourier transform infrared spectroscopy (FTIR), thermogravimetric analysis (TG), Zeta potential, scanning electron microscopy (SEM), pore size distribution analysis (BET), X-ray photoelectron spectroscopy (XPS), specific surface area analysis. The adsorption-resolution conditions of modified CPB were optimized, and their actual removal efficiency for Pb(II) in C-phycocyanin was evaluated. Results showed that CMC-modified CPB (CMC-CPB) had higher thermal stability, rougher and more porous surface, larger specific surface area (20.28±1.35 m²/g), lower zeta potential, stronger metal ion adsorption capacity, and higher regeneration efficiency compared with CPB and Gel-CPB. FTIR showed the functional group of CPB had significant difference after modification, and the main group in CPB were carboxyl, hydroxyl, and amino groups. TG analysis presented the thermal stability of CMC-CPB was higher than that of CPB and Gel-CPB. XPS analysis showed CMC-CPB had the strongest absorption peak for Pb(II). The optimal pH and temperature for the three adsorbents (CPB, Gel-CPB, and CMC-CPB) to remove Pb(II) were 6.0 and 60 ℃, respectively. The Pb(II) adsorption process of all three adsorbents fit the Langmuir isotherm model (R²=0.9543~0.9811) and the pseudo-second-order kinetic model (R²=0.9963~0.9991), and the adsorption process belonged to the monolayer chemical adsorption, involving the complexation of -COO, -OH, -CO-NH, and Pb(II). Based on the Langmuir model curve, the maximum adsorption capacity (q_max) of CMC-CPB for Pb(II) was 69.37 mg/g, significantly higher than that of Gel-CPB and CPB (P<0.05). Combing application effect of three adsorbents in C-phycocyanin, CMC-CPB showed a great prospect to efficiently remove Pb(II) in food of algae and C-phycocyanin at low-cost and environment friendly.
- Chitosan-pectin gel beads,
- modification,
- adsorption,
- C-phycocyanin,
- Pb(II)

FullText(HTML)

References (30)

References

[1]	CALELLA P, DIO M D, CERULLO G, et al. Antioxidant, immunomodulatory, and anti-inflammatory effects of Spirulina in disease conditions:a systematic review[J]. International Journal of Food Sciences and Nutrition,2022,196:46−53.
[2]	关瑞, 王玉, 曹雷鹏, 等. 螺旋藻中分析级藻蓝蛋白的高效制备[J]. 南昌大学学报(理科版),2023,47(2):157−164 GUAN R, WANG Y, CAO L P, et al. Efficient production of analytical-grade phycocyanin from Spirulina platensis[J]. Journal of Nanchang University (Natural Science),2023,47(2):157−164.
[3]	LAFARGA T, FERNANDEZ-SEVILLA J M, LOPEZ C G, et al. Spirulina for the food and functional food industries[J]. Food Research International,2020,137:109−356.
[4]	SONI R A, SUDHAKAR K, RANA RS. Spirulina from growth to nutritional product:A review[J]. Trends in Food Scince & Technology,2017,69:157−171.
[5]	BLANCO-VIEITES M, SUAREZ-MONTES D, DELGADO F, et al. Removal of heavy metals and hydrocarbons by microalgae from wastewater in the steel industry[J]. Algal Research,2022,64:102700. doi: 10.1016/j.algal.2022.102700
[6]	彭晓夏, 崔泾洁, 逯晓青, 等. 向日葵盘低酯化果胶对重金属离子Pb²⁺吸附性能研[J]. 食品工业科技,2022,43(6):25−32 PENG X X, CUI J J, LU X Q, et al. Study on the absorption of heavy metal ion pb²⁺ by the low methoxy pectin from sunflower heads[J]. Science and Technology of Food Industry,2022,43(6):25−32.
[7]	LIU J H, ZHU C W, LI Z P, et al. Screening of Spirulina strains for high copper adsorption capacity through Fourier transform infrared spectroscopy[J]. Frontiers in Microbiology,2022,13:1−10.
[8]	XIANG H R, MIN X B, TANG C J, et al. Recent advances in membrane filtration for heavy metal removal from wastewater:A mini review[J]. Journal of Water Process Engineering,2022,49:103023. doi: 10.1016/j.jwpe.2022.103023
[9]	XU Z, ZHANG Q R, LI X C, et al. A critical review on chemical analysis of heavy metal complexes in water/wastewater and the mechanism of treatment methods[J]. Chemical Engineering Journal,2022,429:131688. doi: 10.1016/j.cej.2021.131688
[10]	WANG R S, LIANG R H, DAI T T, et al. Pectin-based adsorbents for heavy metal ions:A review[J]. Trends in Food Science & Technology,2019,91:319−329.
[11]	ARACHCHIGE M P M, MU T H, MA M M. Effect of high hydrostatic pressure-assisted pectinase modification on the Pb²⁺ adsorption capacity of pectin isolated from sweet potato residue[J]. Chemosphere,2021,262:128102. doi: 10.1016/j.chemosphere.2020.128102
[12]	CHANG C, ZHAN Y F, WU Y, et al. TiO₂/rectorite-trapped cellulose composite nanofibrous mats for multiple heavy metal adsorption[J]. International Journal of Biological Macromolecules,2021,183:245−253. doi: 10.1016/j.ijbiomac.2021.04.085
[13]	AHMAD M, MANZOOR K, IKRAM S. Versatile nature of hetero-chitosan based derivatives as biodegradable adsorbent for heavy metal ions:A review[J]. International Journal of Biological Macromolecules,2017,105:190−203. doi: 10.1016/j.ijbiomac.2017.07.008
[14]	SHAO Z Y, LU J L, DING J, et al. Novel green chitosan-pectin gel beads for the removal of Cu(II), Cd(II), Hg(II) and Pb(II) from aqueous solution[J]. International Journal of Biological Macromolecules,2021,176:217−225. doi: 10.1016/j.ijbiomac.2021.02.037
[15]	王学栋, 李娅, 戴涛涛, 等. 果胶/聚间苯二胺凝胶珠的制备和表征及其对铅吸附性能的研究[J]. 食品工业科技,2021,42(15):85−95 WANG X D, LI Y, DAI T T, et al. Preparation and characterization of pectin/poly (m-phenylenediamine) gel beads and their adsorption properties for lead (II)[J]. Science and Technology of Food Industry,2021,42(15):85−95.
[16]	NIE Z P, WAN C P, CHEN C Y, et al. Comprehensive evaluation of the postharvest antioxidant capacity of Majiayou pomelo harvested at different maturities based on PCA[J]. Antioxidants,2019,8(5):8050136.
[17]	ZHANG C, ZHU X X, ZHANG F P, et al. Improving viscosity and gelling properties of leaf pectin by comparing five pectin extraction methods using green tea leaf as a model material[J]. Food Hydrocolloids,2020,98:105246. doi: 10.1016/j.foodhyd.2019.105246
[18]	罗君兰, 刘玉珍, 熊华, 等. 不同提取方法对白木通果胶的结构及凝胶性与乳化性的影响[J]. 南昌大学学报:理科版,2020,44(5):430−438 LUO JL, LIU YZ, XIONG H, et al. Effects of different extraction methods on the structure, gelatinization and emulsification of Albatron pectin[J]. Journal of Nanchang University:Science Edition,2020,44(5):430−438.
[19]	ZHU W, YANG J, HU D, et al. Removing Pb²⁺with a pectin-rich fiber from sisal waste[J]. Food & Function,2021,12(6):2418−2427.
[20]	ZHANG W, SONG J, HE Q, et al. Novel pectin based composite hydrogel derived from grapefruit peel for enhanced Cu(II) removal[J]. Journal of Hazardous Materials,2019,384:121445.
[21]	KARMAKAR M, MONDAL H, MAHAPATRA M, et al. Pectin-grafted terpolymer super-adsorbent via N-H activated strategic protrusion of monomer for removals of Cd(II), Hg(II) and Pb(II)[J]. Carbohydrate Polymers,2019,206:778−791. doi: 10.1016/j.carbpol.2018.11.032
[22]	ONDITI M, ADELODUN A A, CHANGAMU E O, et al. Removal of Pb²⁺ and Cd²⁺ from drinking water using polysaccharide extract isolated from cactus pads ( Opuntia ficus indica)[J]. Journal of Applied Polymer Science,2016,133(38):43913.
[23]	IBARRA-RODRIGUEZ D, LIZARDI-MENDOZA J, LOPEZ-MALDONADO E A, et al. Capacity of ‘Nopal’ pectin as a dual coagulant-flocculant agent for heavy metals removal[J]. Chemical Engineering Journal,2017,323:19−28. doi: 10.1016/j.cej.2017.04.087
[24]	DARVANJOOGHI M, DAVOODI S M, DURSUN A, et al. , Application of treated eggplant peel as a low-cost adsorbent for water treatment toward elimination of Pb(II):Kinetic modeling and isotherm study[J]. Adsorption Science & Technology,2018,36(3-4):1112−1143.
[25]	ZHOU Y, LIU Z, BO A, et al. Simultaneous removal of cationic and anionic heavy metal contaminants from electroplating effluent by hydrotalcite adsorbents with disulfide (S2) intercalation[J]. Journal of Hazardous Materials,2020,382:121111. doi: 10.1016/j.jhazmat.2019.121111
[26]	FENG G R, MA J C, ZHANG X P, et al. Magnetic natural composite Fe₃O₄-chitosan@bentonite for removal of heavy metals from acid mine drainage[J]. Journal of Colloid & Interface Science,2019,538:132−141.
[27]	LIANG S, GUO X Y, FENG N C, et al. Isotherms, kinetics, and thermodynamic studies of adsorption of Cu(II) from aqueous solutions by Mg²⁺/K⁺ type orange peel adsorbents[J]. Journal of Hazardous Materials,2010,174(1-3):756−762. doi: 10.1016/j.jhazmat.2009.09.116
[28]	MALIK P K. Dye removal from wastewater using activated carbon developed from sawdust:Adsorption equilibrium and kinetics[J]. Journal of Hazardous Materials,2004,113(1-3):81−88. doi: 10.1016/j.jhazmat.2004.05.022
[29]	YU LL, JIANG LN, WANG SY, et al. Pectin microgel particles as high adsorption rate material for methylene blue:Performance, equilibrium, kinetic, mechanism and regeneration studies[J]. International Journal of Biological Macromolecules,2018,112:383−389. doi: 10.1016/j.ijbiomac.2018.01.193
[30]	NIU H Y, LI X T, LI J S. Dithiocarbamate modification of activated carbon for the efficient removal of Pb (Ⅱ), Cd (Ⅱ), and Cu (Ⅱ) from wastewater[J]. New Journal of Chemistry,2022,46(11):5234−5245. doi: 10.1039/D1NJ05293D
